Xerox PHASER 7500 Service Manual

9-102 Phaser 7500 Printer Service Manual
Parts List
Parts List 18.1 Electrical (1 of 2)
Item Description Part Number
1 Main Power Switch Chassis Assembly (REP 18.1, page 8-186) See item 24
2 Main Switch Harness Guide
3 Cam Chassis Assembly (REP 18.2, page 8-188)
4 MOB ADC Assembly (REP 18.3, page 8-189) 130K71470
5 HVPS Housing Assembly 848K13850
6 HVPS Guide 032E27481
7 HVPS (DEVE/ BCR) (REP 18.4, page 8-191) 105E17521
8 Wire Harness Assembly (UI) 962K60382
9 Front Cover Interlock Switch (Push CS3A-B2CA) (REP 18.5, page 8-192) 110E12981
10 IBT Front Cover Switch (REP 18.6, page 8-193)
11 Main LVPS (100-127V) (REP 18.7, page 8-194) 105K23374
Main LVPS (220-240V) (REP 18.7, page 8-194) 105K23382
12 Bracket
13 LV Fan (REP 18.8, page 8-195) 127K56990
14 Thermo Sensor 130K88740
15 GFI (REP 18.9, page 8-196) 908W01201
16 GFI Chassis
17 Bracket
18 Wire Harness Assembly 962K60620
19 Screw
20 Wire Harness (AC Main) (110V) 962K69350
21 Knurling Screw
22 Stopper
23 Power Cord Refer to “Xerox
Supplies and
Accessories” on
page 9-114
24 Main Power Switch Kit (items 1,3) 604K49660

Xerox PHASER 7500 Specifications

General

Max Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	150, 000 pages
Standard Paper Capacity	550 sheets
Duplex Printing	Optional
Standard Memory	256 MB
Network Connectivity	10/100/1000Base-T Ethernet
Supported Operating Systems	Windows, Mac OS, Linux
Max Paper Capacity	2, 100 sheets
Connectivity	USB 2.0, Ethernet
PDL	PostScript 3, PCL 6, PDF
Print Speed	Up to 35 ppm
