Xerox PHASER 7500 Service Manual

9-106 Phaser 7500 Printer Service Manual
Parts List
Parts List 18.3 PWB Chassis Unit
Item Description Part Number
1EEPROM
2 Backplane PWB (REP 18.11, page 8-200) 960K47810
3 Wire Harness BP-UI 962K60890
4Clamp
5 EEPROM (for MCU)
6 MCU PWB (REP 18.12, page 8-202) 960K50520
MCU PWB (REP 18.12, page 8-202) (Dell 7130) 960K51270
7 Motor Drive PWB (REP 18.13, page 8-204) 960K32651
8 ESS Cover
9 Chassis Assembly
10 PWB Spacer
11 TM Relay PWB (REP 18.14, page 8-205) 960K35401
12 Wire Harness Assembly (ESS2) 962K60720
13 Wire Harness Assembly OP Tray 962K60370
14 Screw
15 Guide
16 Fan Bracket
17 Drive Fan (REP 18.15, page 8-206) 127K53040
18 Connector
