Xerox PHASER 7500 Service Manual

Phaser 7500 Printer Service Manual 9-111
Parts List
Parts List 19.2 Cover/ Control Panel
Item Description Part Number
1 Top Cover Assembly (items 2, 3) (REP 19.2, page 8-211) 848K03124
Top Cover Assembly (items 2, 3) (REP 19.2, page 8-211) (Dell 7130) 848K16233
2Top Cover
3 Top Right Cover
4 Number Label
5 Exit Cover Assembly (REP 19.5, page 8-216) 848K26921
6 Top Rear Cover (REP 19.6, page 8-217) 848E21691
7 Front Left Cover (REP 19.7, page 8-218) 848E21730
8 Right Cover (REP 19.8, page 8-219) 848E21711
9 Rear Cover (REP 19.6, page 8-217) 848E21722
10 Data Plate
11 Ground Label
12 GFI Label
13 Console Panel (REP 19.2, page 8-211) 848E51510
Console Panel (REP 19.2, page 8-211) (Dell 7130) 848E57520
14 Console Harness Assembly 962K60661
15 Fan Guard 055E56421
16 Foot
17 Upper Table (Option)
18 Lower Table (Option)
19 Table Plate (Option)
20 MPT Front Cover (REP 19.3, page 8-214) 848E21212
21 Left Rear Cover (REP 19.4, page 8-215) 848E21750
22 Label
23 Filter Kit (items 24, 25, PL 4.1 - item 7, page 9-21)
24 Filter 053K92980
25 Filter Case

Xerox PHASER 7500 Specifications

General

Max Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	150, 000 pages
Standard Paper Capacity	550 sheets
Duplex Printing	Optional
Standard Memory	256 MB
Network Connectivity	10/100/1000Base-T Ethernet
Supported Operating Systems	Windows, Mac OS, Linux
Max Paper Capacity	2, 100 sheets
Connectivity	USB 2.0, Ethernet
PDL	PostScript 3, PCL 6, PDF
Print Speed	Up to 35 ppm
