Phaser 7500 Printer Service Manual 9-113
Parts List
Parts List 35.1 ESS
Item Description Part Number
1 Control Unit (items 2-7, 12) 960K58360
2 Handle Plate
3 Control Chassis Assembly
4 ESS PWB (Image Processor Board) (REP 35.1, page 8-220) 960K58360
ESS PWB (Image Processor Board) (REP 35.1, page 8-220) (Dell 7130) 960K59311
5 Front Panel
6Screw
7Handle
8 512 MB SODIMM RAM 237E25310
512 MB SODIMM RAM (Dell 7130) 133K27870
1GB Memory SODIMM RAM (Dell 7130) 237E25600
9 Internal Hard Drive Kit (items 9-13) 604K60890
Internal Hard Drive Kit (items 9-13) (Dell 7130) 650K32420
10 HD Interface Board
11 Configuration Chip, Network 237E25320
Configuration Chip, Network (Dell 7130) 237E25580
12 I/P Board EEPROM 237E25330
13 Wire Harness
14 Wire Harness
