QoS Configuration
Except on the first page, right running head:
Heading1 or Heading1NewPage text (automatic)
997
Alcatel-Lucent
Beta Beta
OmniAccess 5740 Unified Services Gateway CLI Configuration Guide
TO SET TRAFFIC SHAPING
The main objective of the traffic shaper is to allow the traffic in to the network at a
controlled rate from different sources so that the network resources are optimally
utilized for better performance. Typically this is achieved by applying a Token
Bucket Filter at the egress of an interface. Tokens will be generated per each flow
at a sustained rate (configured as CIR) and are emptied as and when the packets
are transmitted.
E
XAMPLE
ALU(config-qos-P1-C1)# shape committed-rate 500000
committed-burst 7812
ALU(config-qos-P1-C1)# no shape
Command (in Class Mode) Description
shape committed-rate <8000-
10000000> committed-burst <40-
200000> peak-rate <8000-10000000>
excess-burst <40-200000>
This command sets QoS shaping
parameters on the policy map’s
traffic class.
Note: It is preferable to
configure committed
burst/excess burst as
125 milliseconds of
the specified
committed/peak rate.
For example, if
committed rate is 500
kbps, then committed
burst will be
((500000/8)*125/
1000) = 7812 bytes.
no shape This command removes the
configured shaping parameters.
