QoS on Frame Relay (Per-PVC Queuing)
Except on the first page, right running head:
Heading1 or Heading1NewPage text (automatic)
1029
Alcatel-Lucent
Beta Beta
OmniAccess 5740 Unified Services Gateway CLI Configuration Guide
Note: The above steps can be skipped if you are configuring FR on a Serial interface (V.35/
X.21). The steps (Step 6 - Step 12) hold good for configuration of FR on a V.35/X.21
interface, except that there is no channel group number in the interface name.
Configure a serial interface using the following command:
ALU(config)# interface Serial <slot/port>
ALU(config-if Serial<slot/port>)#
Example:
ALU(config)#interface Serial0/0
ALU(config-if Serial0/0)#
For more details on configuring a Serial interface (V.35/X.21), refer to “Universal Serial
Port (USP) Line Card” chapter.
Step 6: Enter Serial interface configuration mode for Member Link Configuration
ALU(config)# interface Serial <slot/port:channel>
ALU(config-if Serial<slot/port:channel>)#
Example:
ALU(config)#interface Serial0/0:0
ALU(config-if Serial0/0:0)#
Step 7: Administratively bring up the interface
ALU(config-if <interface-name>)# no shutdown
Example:
ALU(config-if Serial0/0:0)# no shutdown
Step 8: Configure IP address for the interface
ALU(config-if <interface-name>)# ip address {<ip-
address subnet-mask>|<ip-address/prefix-length>}
Example:
ALU(config-if Serial0/0:0)# ip address 20.20.20.20/24
Step 9: Set FR encapsulation on the interface.
ALU(config-if <interface-name>)# encapsulation frame-
relay
Example:
ALU(config)#interface Serial0/0:0
ALU(config-if Serial0/0:0)# encapsulation frame-relay
