T1E1 Line Card
Left running head:
Chapter name (automatic)
260
Beta Beta
OmniAccess 5740 Unified Services Gateway CLI Configuration Guide
Alcatel-Lucent
T
O CONFIGURE CHANNELIZED E1
The controller can be channelized. This implies that more than one channel-group
can be configured on a controller.
Note: The OmniAccess 5740 USG supports unframed E1 and channelized E1. You can
configure only 20 channel groups per card.
E
XAMPLE
The following example configures a channel group on controller E1 at the first slot
and at the 0th port:
1. Variations of the channel-group to associate different timeslots with the
serial interface are shown:
To associate all the timeslots with the controller:
ALU(config-controller E1)#channel-group 0 timeslots 1-31
To associate contiguous timeslots with the controller:
ALU(config-controller E1)#channel-group 0 timeslots 1-10
ALU(config-controller E1)#channel-group 0 timeslots 4,5,6
To associate non-contiguous timeslots with the controller:
ALU(config-controller E1)#channel-group 0 timeslots 1,4,20
2. In the above example, the channel-group command is shown only with a
value of ‘0’. Now the values in the range of 0-30 can be used:
Command (in CCM) Description
channel-group <0-30> timeslots
<1-31> speed [56K|64K]
This command is used to create
channel-groups that vary from 0-30 and
set timeslots that vary from 1-31. This
enables the interface on the controller.
Default value of speed: 64 Kbps.
no channel group <0-30> This command removes the channel
group configured on the controller.
