E1 Configuration
Except on the first page, right running head:
Heading1 or Heading1NewPage text (automatic)
261
Alcatel-Lucent
Beta Beta
OmniAccess 5740 Unified Services Gateway CLI Configuration Guide
To configure multiple channel groups, with absolute values of timeslots
ALU(config-controller E1)#channel-group 0 timeslots 1
ALU(config-controller E1)#channel-group 1 timeslots 2
To configure multiple channel groups, with contiguous values of timeslots
ALU(config-controller E1)#channel-group 3 timeslots 10-13
To configure multiple channel groups, with non-contiguous values of timeslots
ALU(config-controller E1)#channel-group 2 timeslots 3,6,9
Note: Timeslots cannot overlap, hence one timeslot cannot be part of more than one
channel-group.
T
O BRING UP/SHUTDOWN THE E1 CONTROLLER
EXAMPLE
The following example administratively brings up the controller:
ALU(config)#controller E1 1/0
ALU(config-controller E1)# no shutdown
The following example shuts down the controller:
ALU(config)# controller E1 1/0
ALU(config-controller E1)# shutdown
Note: Online Insertion and Removal (OIR) functionality is supported on the T1 and E1 cards.
After re-insertion, the default state of the controller is in ‘shutdown’ state.
Command (in CCM) Description
no shutdown This command is used in the Controller
Configuration Mode.
This command is used to administratively
bring up the controller.
shutdown This command is entered in the controller
configuration mode to administratively bring
down the controller.
