T1E1 Line Card
Left running head:
Chapter name (automatic)
262
Beta Beta
OmniAccess 5740 Unified Services Gateway CLI Configuration Guide
Alcatel-Lucent
T
O CONFIGURE UNFRAMED E1
E1 controller can be configured as unframed, which is also known as the "clear
channel mode". If the controller is configured in unframed mode:
• System creates channel group 0 comprising of all timeslots.
• There is no provision to configure a channelized or framed E1. This implies that
unframed and channelized functionality are mutually exclusive.
Following are the sequence of commands to configure E1 into Unframed mode.
‘No’ version of this command will restore the default framing mode, i.e., esf.
ALU(config)#controller E1 0/0
ALU(config-controller E1)#no shutdown
ALU(config-controller E1)#unframed
ALU(config-controller E1)#no unframed
As system is creating channel-group 0, serial interface will be available, and you
will require to configure it too.
ALU(config)#interface Serial 0/0:0
ALU(config-if Serial0/0:0)#no shutdown
