PIM Configuration
Except on the first page, right running head:
Heading1 or Heading1NewPage text (automatic)
625
Alcatel-Lucent
Beta Beta
OmniAccess 5740 Unified Services Gateway CLI Configuration Guide
TO VIEW BSR INFORMATION
EXAMPLE
ALU(config)# show ip pim bsr-router
PIMv2 Bootstrap information
This system is the Bootstrap Router (BSR)
BSR Address: 1.1.1.2 (?)
Uptime: 00:04:24, BSR Priority: 0, Hash Mask Length: 30
Next Bootstrap Message in 00:00:46 seconds
Candidate RP: 2.2.2.1 (GigabitEthernet3/0), Group Acl: test
Next Cand_RP_Advertisement in 00:00:35 seconds
ALU(config)#
TO VIEW SG STATE INFORMATION
EXAMPLE
ALU# show ip pim state-info
PIMv2 State information
Flags: M - Nexthop from Mroute, T - Terminating
K - KeepAlive Timer Running, S - SPT bit set
(*,224.1.1.1), JOINED 00:00:55/00:00:05, RP 5.5.5.5, flags:
Incoming interface: GigabitEthernet3/1, RPF neighbor 5.5.5.5
Downstream interface state:
GigabitEthernet3/0, 00:00:55, flags:A
inherited_olist: GigabitEthernet3/0
Command (in SUM/CM) Description
show ip pim bsr-router This command displays the BSR
information.
Command (in SUM/CM) Description
show ip pim state-info [<group-
address>] [<source-address>]
[summary]
This command displays the PIM
upstream (towards RP/Source) and
downstream (towards Receivers)
state information.
