System Configuration and Monitoring
Left running head:
Chapter name (automatic)
56
Beta Beta
OmniAccess 5740 Unified Services Gateway CLI Configuration Guide
Alcatel-Lucent
The following table lists the traceroute command field descriptions:
Field Description
Enter the Target IP address: Enter an IP address. There is no default.
Enter the Source IP Address: The interface or IP address of the
OmniAccess 5740 USG to be used as a
source address for the probes. If source
IP address is not specified, the router
normally picks the IP address of the
outbound interface to use.
Enter the source interface: Specify the outbound interface to send
the trace packets through. Is useful
when there are two routes for a
destination. Trace packets will have the
interface's IP address as source IP
address.
Enter the Datagram Size[38]: Specify the ICMP payload size (in bytes)
in the range 36-18024.
Default size is 38 bytes.
Enter the Timeout value[2]: Enter the number of seconds to wait for
a response to a probe the packet.
The range being 1-3600 (in seconds).
The default is 2 seconds.
Enter the Probecount[3]: Enter the number of probes to be sent at
each TTL level in the range 1-10.
The default count is 3.
Enter the Minimum TTL[1]: The TTL value for the first probe in the
range 1-255.
The default is 1, but it can be set to a
higher value to suppress the display of
known hops.
Enter the Max TTL[30]: The largest TTL value that can be used
in the range 1-255. The traceroute
command terminates when the
destination is reached or when this value
is reached.
The default is 30.
The maximum TTL value should be
greater than the minimum TTL value.
Enter the Destination
Port[33434]:
The destination port to be used by the
UDP probe messages. Port number to
be between 1-65535.
The default is 33434.
