524 EDIUS — User Reference Guide
Section 6 — Effects and Titles
When overlaying one video clip on another, the layering order is deter-
mined by the track order. For example, if video “B” is on the V1 track and
video “A” is on the V2 track, when video ‘A” is composited with video “B”
in a picture-in-picture overlay, video “B” is the background and video “A”
occupies the picture-in-picture window as illustrated in Figure 603.
Figure 603. Video Overlay Priority
Composition
A composition video is created by layering two video sources in a blend
effect.
To create a composition video, do the following:
1. Select the “Keyers” tree from the Effect Palette as shown in Figure 604.
2. Select the “Blend” tree and drag and drop the desired blend effect to the
Mixer area of a clip.
Note If the Effect view is hidden, the blend effects will be listed under the Blend tree
in the Effect Palette.
