656 EDIUS — User Reference Guide
Section 7 — Audio Operations
Figure 804. Audio Mixer Track Reset
Ganging Audio Tracks
Audio tracks may be ganged together in order to adjust all ganged tracks
simultaneously. Three separate gangs may be created and are assigned the
colors of yellow (
Gang 1), red ( Gang 2) and, blue ( Gang 3).
Each audio track has three Gang buttons above the meter bars and fader.
From left to right these are Gang1, Gang2 and Gang3.
To gang tracks and adjust them simultaneously, do the following:
1. On any audio track you wish to gang, click the Gang button (Gang1,
Gang2 or Gang3) to which you wish to assign the track.
The gang button and audio track fader change to the color of the selected
gang (yellow, red or blue).
2. Adjust the fader on one of the ganged tracks.
All ganged track faders move together. See Figure 805
Note The fader is not active if the track operation is set to “None.” See Audio Track
Operations on page 654 for more information.
