● Client mode: Client with KEY-PLUG W740 iFeatures (MLFB 6GK5 907-4PA00)
● The management interface and data interface must be operated in the same frequency
band and mode and must match in terms of their wireless coverage. iPCF-MC will not work
if both wireless interfaces are equipped with directional antennas that cover different areas.
● The management interfaces of all access points to which a client can change must use the
same channel. A client scans only this one channel to find accessible access points.
● Transmission based on IEEE801.11h (DFS) cannot be used for the management interface.
801.11h (DFS) is possible for the data interface.
● The client cannot be operated with "Use Allowed Channel only".
● "Force roaming on Ethernet down" is automatically mirrored on the second interface.
● The following applies to clients: All configured and active SSIDs must be assigned to
security context 1. An SSID is active when the corresponding check box "Enabled" is
selected on the page "Interfaces > WLAN > Client".
● In Japan, iPCF-MC cannot be enabled if the data or management interface uses a
frequency of the 4920 MHz - 5080 MH frequency band.
Syntax
Call the command without parameter assignment:
wlan ipcf-mc
Result
iPCF-MC is enabled.
Further notes
You disable iPCF-MC with the no wlan ipcf-mc command.
You display the setting with the show wlan ipcf-mc command.
5.6.2.2 no wlan ipcf-mc
Note
The command is only available if the SCALANCE W700 device supports iPFC-MC or the
function can be enabled.
● iPCF-MC is enabled with the aid of the following KEY-PLUGs:
– W780 iFeatures (MLFB 6GK5 907-8PA00)
– W740 iFeatures (MLFB 6GK5 907-4PA00)
Description
With this command, you disable iPCF-MC on this SCALANCE W700 device.
Functions specific to SCALANCE
5.6 iPCF-MC
SCALANCE W770/W730 acc. to IEEE 802.11n Command Line Interface
Configuration Manual, 09/2017, C79000-G8976-C324-08 141
