7.1.5.52 wlan ht channel width (access point)
Description
With this command, you specify the channel bandwidth. With IEEE 802.11n, data can be
transferred via two directly neighboring channels (channel bonding). The two 20 MHz channels
are put together to form one channel with 40 MHz channel bandwidth
Note
This command is available only in access point mode.
Requirement
You are in the Interface Configuration mode of the WLAN interface.
The command prompt is as follows:
cli (config-if-wlan-0-X)#
Syntax
Call up the command with the following parameters:
wlan ht channel width { HT-20 | HT-40-UP | HT-40-DOWN }
The parameters have the following meaning:
Parameters Description
HT-20 Channel bandwidth 20 MHz
HT-40-UP Channel bandwidth 40 MHz. The configured channel and the neighboring
channel above it are used. (default setting)
HT-40-DOWN Channel bandwidth 40 MHz. The configured channel and the underlying
neighboring channel are used.
Note
Channel bandwidth 40 MHz and frequency band 2.4 GHz
If the access point detects another access point on the configured channel or on neighboring
channels, the access point changes the channel bandwidth from 40 MHz to 20 MHz. If you set
a "free" channel on the access point, the access point uses the channel bandwidth 40 MHz.
Result
The channel bandwidth is set.
Further notes
You display the setting with the show wlan ap <wlan 0/X> command.
Network structures
7.1 WLAN
SCALANCE W770/W730 acc. to IEEE 802.11n Command Line Interface
254 Configuration Manual, 09/2017, C79000-G8976-C324-08
