Parameter Description Range of values / note
src-port-number Source port number 1 ... 65535
dest-port-number Destination port number
gt Keyword for port numbers higher than
the specified number (gt: greater than).
-
lt Keyword for port numbers lower than
the specified number (lt: less than).
-
eq Keyword for a specific port number
(eq:equal).
-
range Keyword for a range of port numbers.
Following this, the first and last port
number of the range is specified.
-
any Forwards all outgoing TCP segments. -
host Keyword for a an individual IPv4 ad‐
dress
-
dest-ip-address Destination IPv4 address Enter a valid IPv4 address.
dest-ip-address Network destination address Enter a valid combination of IPv4
address and subnet mask.
dest-mask Corresponding subnet mask
dscp Keyword for the Differentiated Services
Codepoint
-
value Value for the Differentiated Services Co‐
depoint
0 ... 63
For information on names of addresses and interfaces, refer to the section "Interface identifiers
and addresses (Page 29)".
Result
The IP access list for UDP datagrams has been configured.
Note
Subnet mask for individual hosts
If you create the rule for a single system (one IPv4 address), specify the subnet mask
"255.255.255.255". As an alternative, you can specify the keyword "host" followed by the IPv4
address.
Further notes
You delete an IP access control list with the no ip access-list standard <acl-
num> command.
You display the configuration of the access control list with the show access-lists
command.
Security and authentication
11.5 IP access control list
SCALANCE W770/W730 acc. to IEEE 802.11n Command Line Interface
574 Configuration Manual, 09/2017, C79000-G8976-C324-08
