Xerox PHASER 7500 Service Manual

Phaser 7500 Printer Service Manual 2-69
Theory of Operation
Status of the Tray Paper Size Sensor Switches and Paper Size (Standard Tray)
Paper Size SW1 SW2 SW3 SW4 SW5 AD Value
No Tray OFF OFF OFF OFF OFF 922 - 989
A5 SEF/ 5.5" x 8.5" SEF OFF OFF ON OFF OFF 797 - 857
B5 SEF OFF OFF ON ON ON 735 - 796
8.5" x 13" SEF OFF ON OFF ON OFF 610 - 671
A4 SEF OFF ON ON OFF OFF 548 - 609
8.5" x 11" SEF OFF ON ON OFF ON
A4 LEF ON OFF ON OFF OFF 304 - 365
A3 SEF ON OFF ON ON OFF 244 - 303
B5 LEF/ 7.25" x 10.25"
LEF
ON ON OFF OFF ON 184 - 243
8K SEF ON ON OFF ON OFF 124 - 183
B4 SEF ON ON OFF ON ON
8.5" x 11" LEF ON ON ON OFF OFF 64 - 123
16K LEF/ 7.25" x 10.5"
LEF
ON ON ON OFF ON
11" x 17" SEF ONONONONON 0 - 63
Status of the Tray Paper Sensor Switches and Paper Size (Optional Tray
Module)
Paper Size SW1 SW2 SW3 SW4 SW5 AD Value
No Tray OFF OFF OFF OFF OFF 237 - 247
A5 SEF/ 5.5" x 8.5" SEF OFF OFF ON OFF OFF 199 - 214
B5 SEF OFF OFF ON ON ON 184 - 198
8.5" x 13" SEF OFF ON OFF ON OFF 153 - 167
8.5" x 14" SEF OFF ON OFF ON ON
A4 SEF OFF ON ON OFF OFF 137 - 152
8.5" x 11" SEF OFF ON ON OFF ON
8" x 10" SEF OFF ON ON ON ON 122 - 136
12.6" x 19.2" SEF/
13" x 19" SEF*
ON OFF OFF OFF ON 107 - 121
SRA3 SEF/ 13" x 18" SEF/
2" x 18" SEF*
ON OFF OFF ON ON 92 - 106
A4 LEF ON OFF ON OFF OFF 77 - 91
A3 SEF ON OFF ON ON OFF 61 - 76
B5 LEF/ 7.25" x 10.25"
LEF
ON ON OFF OFF ON 46 - 60

Xerox PHASER 7500 Specifications

General

Max Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	150, 000 pages
Standard Paper Capacity	550 sheets
Duplex Printing	Optional
Standard Memory	256 MB
Network Connectivity	10/100/1000Base-T Ethernet
Supported Operating Systems	Windows, Mac OS, Linux
Max Paper Capacity	2, 100 sheets
Connectivity	USB 2.0, Ethernet
PDL	PostScript 3, PCL 6, PDF
Print Speed	Up to 35 ppm
