Xerox PHASER 7500 Service Manual

2-70 Phaser 7500 Printer Service Manual
Theory of Operation
Tray 1 (MPT)
Load paper into Tray 1 and align the Front Side Guide and Rear Side Guide. As the
guide positions change, the variable resistance of the Tray 1 Paper Size Sensor also
changes, which changes the output voltage.
The paper width is detected by the value of the output voltage.
8K SEF ON ON OFF ON OFF 31 - 45
B4 SEF ON ON OFF ON ON
8.5" x 11" LEF ON ON ON OFF OFF 16 - 30
16K LEF/ 7.25" x 10.5"
LEF
ON ON ON OFF ON
11" x 17" SEF ONONONONON 0 - 15
* Only for Single Tray Module (STM)
Status of the Tray Paper Sensor Switches and Paper Size (Optional Tray
Module)
Paper Size SW1 SW2 SW3 SW4 SW5 AD Value
s7500-422
Front Side Guide
Rear Side Guide
MSI Paper Size Sensor
