Xerox PHASER 7500 Service Manual

3-8 Phaser 7500 Printer Service Manual
Error Messages and Codes
042-323 Drum K Motor Fail 3-111
042-324 IBT Motor Fail 3-113
042-325 Main Motor Fail 3-115
042-329 HV Fan Fail 3-117
042-334 IBT Fan Fail 3-118
042-336 Process 2 Fan Fail 3-120
042-337 NOHAD Logic Fail 3-122
042-338 LVPS Exhaust Fan Fail 3-123
042-343 Rear Bottom Fan Fail 3-124
042-400 Deodorant Filter Life End N/A
042-604 NOHAD Temperature Sensor Fail 3-126
042-605 Drive Fan Fail 3-127
045-310 Image Ready NG 3-129
045-311 Controller Communication Fail 3-129
045-312 Drive Logic Fail 3-130
045-313 ENG_LOGIC_FAIL 3-131
045-321 MK_Panel_NG 3-132
045-322 MI_Pitch_NG 3-133
045-331 MK_MKIF_MSG_Reject 3-134
045-332 MK_MMIF_MSG_Reject 3-135
045-340 ENG_Emergency_Over_Wait 3-136
045-341 ENG_Emergency_No_Timer 3-137
045-342 ENG_Emergency_Enforced_Stop 3-138
045-350 MK_Emergency_Over_Wait 3-139
045-351 MK_Emergency_No_Timer 3-140
045-352 MK_Emergency_Enforced_Stop 3-141
047-320 All Destination Tray Broken 3-142
061-350 LPH Power On Fail Y 3-143
061-351 LPH Power Fail M 3-145
061-352 LPH Power Fail C 3-147
061-353 LPH Power Fail K 3-149
061-354 LPH Download Data Fail Y 3-151
061-355 LPH Download Data Fail M 3-153
061-356 LPH Download Data Fail C 3-155
061-357 LPH Download Data Fail K 3-157
Error Message and Chain Link Code Display (Continued)
Chain Link Control Panel Message Go to Page

Xerox PHASER 7500 Specifications

General

Max Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	150, 000 pages
Standard Paper Capacity	550 sheets
Duplex Printing	Optional
Standard Memory	256 MB
Network Connectivity	10/100/1000Base-T Ethernet
Supported Operating Systems	Windows, Mac OS, Linux
Max Paper Capacity	2, 100 sheets
Connectivity	USB 2.0, Ethernet
PDL	PostScript 3, PCL 6, PDF
Print Speed	Up to 35 ppm
