Xerox PHASER 7500 Service Manual

3-156 Phaser 7500 Printer Service Manual
Error Messages and Codes
2 Check the following:
■ The Flat Cable between the MCU
PWB J555 and the LPH Rear PWB
(C) J559 for open circuit, short
circuit, and poor contact.
■ The Flat Cable between the LPH H
PWB (C) J567 and the LPH (C)
J575 for open circuit, short circuit,
and poor contact (connection
within the LPH Unit).
■ The connector (P/J579) between
the LPH Rear PWB (C) and the LPH
H PWB (C) for damage and debris.
■ The LPH Unit (C) for improper
installation.
■ Perform the LED EEPROM test in
Diagnostics.
Are they normal, without any short
circuits, poor contacts, and etc.?
Replace the
following parts
in sequence:
■ LPH Unit (C)
(REP 2.1,
page 8-18)
■ LPH Cable
Assembly
■ LPH Rear
PWB (REP
2.4,
page 8-22)
■ MCU PWB
(REP 18.12,
page 8-202)
Repair the
sections that
have short
circuits and
poor contacts.
Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No

Xerox PHASER 7500 Specifications

General

Max Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	150, 000 pages
Standard Paper Capacity	550 sheets
Duplex Printing	Optional
Standard Memory	256 MB
Network Connectivity	10/100/1000Base-T Ethernet
Supported Operating Systems	Windows, Mac OS, Linux
Max Paper Capacity	2, 100 sheets
Connectivity	USB 2.0, Ethernet
PDL	PostScript 3, PCL 6, PDF
Print Speed	Up to 35 ppm
