8-48 Phaser 7500 Printer Service Manual

Service Parts Disassembly

7. Separate Dispenser Pipe Assembly (C/M/Y) from Dispenser Pipe Assembly (K).

s7500-102

Dispense Pipe Assembly (Y,M,C)

Dispense Pipe Assembly (K)
