Phaser 7500 Printer Service Manual 8-113

Service Parts Disassembly

7. Loosen 1 screw (silver, 8mm) that secures the Feed Out Chute and remove the

Feed Out Chute from the Tray 3 Feeder Assembly-STM.

s7500-177

Feed Out Chute
