Parts List
Parts List 3.2 Drive (2 of 3)
Item Description Part Number
1 Main Drive Assembly (items 2, 3) (REP 3.4, page 8-29) 007K98071
2Bracket Assembly
3 Main Drive Motor Assembly (REP 3.5, page 8-30)
4 Retract Drive Assembly (items 5-22) (REP 3.6, page 8-31) 007K98090
5Retract Bracket Assembly
6Retract Lower Bracket
7Retract Shaft
8Clutch Shaft
9 Helical Gear (45T/23T)
10 Helical Gear (36T)
11 Helical Gear (21T)
12 1st BTR Contact Retract Clutch Assembly 121K40850
13 Coupling
14 Retainer
15 Cam Wheel
16 Spring
17 1st BTR Contact Retract Sensor (REP 3.7, page 8-32) 930W00111
18 Sleeve Bearing
19 Sleeve Bearing
20 Connector
21 Harness Holder
22 Harness Holder

Xerox PHASER 7500 Specifications

General

Max Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	150, 000 pages
Standard Paper Capacity	550 sheets
Duplex Printing	Optional
Standard Memory	256 MB
Network Connectivity	10/100/1000Base-T Ethernet
Supported Operating Systems	Windows, Mac OS, Linux
Max Paper Capacity	2, 100 sheets
Connectivity	USB 2.0, Ethernet
PDL	PostScript 3, PCL 6, PDF
Print Speed	Up to 35 ppm
