9-48 Phaser 7500 Printer Service Manual
Parts List
Parts List 9.4 Tray 2 Feeder Assembly (1 of 2)
Item Description Part Number
1 Upper Frame Assembly (P/O PL 9.3.1, page 9-46)
2Drive Bracket Assembly
3 Tray 2 Feed/ Lift Up Motor (REP 9.10, page 8-85)
4Rail
5Chute
6 Tray 2 Nudger Level Sensor (REP 9.12, page 8-86) 930W00111
Tray 2 No Paper Sensor (REP 9.12, page 8-86) 930W00111
7Actuator
8 Upper Harness Holder
9 Rear Harness Holder
10 Gear (31T)
11 Spacer
12 Bearing
13 Drive Shaft
14 Gear (13T)
15 Oneway Clutch
16 Oneway Gear (Alternate)
17 Helical Gear (25T)
18 Helical Gear (29T/19T)
19 Washer
20 Wire Harness (Feeder)
21 Spring
22 Roll Assembly (PL 9.5, page 9-50)
To Next Page
