Xerox PHASER 7500 Service Manual

9-52 Phaser 7500 Printer Service Manual
Parts List
Parts List 10.1 Tray Module (3T)
Item Description Part Number
1 Tray 3 Feeder Assembly (PL 10.3, page 9-56) (REP 10.1, page 8-90) 059K55532
2 Tray 4 Feeder Assembly (PL 10.3, page 9-56) (REP 10.1, page 8-90) 059K55532
Tray 5 Feeder Assembly (PL 10.3, page 9-56) (REP 10.1, page 8-90) 059K55532
3 Feed Out Chute 054E36441
4 Tray 3/4/5 Assembly (PL 10.2, page 9-54) See item 20
5Roller
6Roller
7Stopper 003E75430
8 Tray 3 Paper Size Sensor (REP 10.2, page 8-92) 110K12100
9 Tray 4 Paper Size Sensor (REP 10.2, page 8-92) 110K12100
10 Tray 5 Paper Size Sensor (REP 10.2, page 8-92) 110K12100
11 Sensor Cover
12 Bracket
13 Side Size Label
14 End Size Label
15 Label (Instruction)
16 Tray 3 Label
17 Tray 4 Label
18 Tray 5 Label
19 Slide Lock Block
20 Tray Assy 3TM Kit (items 4, 13-19) 604K52880
Tray Assy 3TM Kit (items 4, 13-19) (Dell 7130) 604K56720
99 Three Tray Module Option Complete 050K68700
Three Tray Module Option Complete (Dell 7130) 059K76390
