9-100 Phaser 7500 Printer Service Manual
Parts List
Parts List 17.1 Exit
Item Description Part Number
1 Exit Assembly (items 2-17) (REP 17.1, page 8-179) 059K62332
2Low Chute
3 Exit Roll (REP 17.2, page 8-180)
4Bearing
5Ground Bearing
6Eliminator
7 Ground Plate
8Exit Chute
9Pinch Spring
10 Pinch Roll
11 Gear (24T)
12 Gear Pulley (41T/ 16T)
13 Ground Plate
14 Bracket Assembly
15 Exit Motor (REP 17.3, page 8-181)
16 Belt
17 Motor Cover
18 Wire Harness (Motor)
19 Full Stack Sensor 930W00111
20 Wire Harness (Full Stack)
21 Full Stack Shaft
22 Spring
23 Pipe
24 Full Stack Actuator
25 Bearing
26 Full Stack Sensor Kit 675K82730
