Phaser 7500 Printer Service Manual 9-109
Parts List
Parts List 19.1 Cover (Front)
Item Description Part Number
1 Filter Cover, IBT 848E18320
2Plate (Y) 815E43211
3Plate (M) 815E43221
4Plate (C) 815E43231
5Plate (K) 848K14912
6Magnet Catch
7Strip (A)
8 -----
9 -----
10 Front Cover Assembly (items 11,12) (REP 19.1, page 8-207) See item 19
Front Cover Assembly (items 11,12) (REP 19.1, page 8-207) (Dell 7130) 604K56730
11 Front Cover
12 Strip (B)
13 Inner Cover Assembly (REP 19.1, page 8-207) 848K27921
14 Guide Assembly (items 15-17)
15 Guide
16 Spring-COMP 809E80970
17 Bracket
18 Block-Key IOT 014E63041
19 Front Cover Unit (items 10-12, 20) 604K55830
20 Logo Plate
99 Plate Kit - CMYK (items 1-5) (Dell 7130) 604K57470
