T
O SET IP/FR/VLAN MARKING
Refer ‘Appendix - QoS Values and Mnemonics’ for IP-DSCP, IP-Precedence,
and ToS mnemonics.
E
XAMPLE
ALU(config-qos-P1-C1)# set ip dscp af11
ALU(config-pmap-c)# no set ip dscp
Deleted ip-dscp marking.
T
O CONFIGURE BANDWIDTH FOR A TRAFFIC CLASS
This command provides a mechanism for bandwidth sharing of the link.
Note: You cannot mix the absolute bandwidth command with percentage bandwidth
command across policy hierarchy.
E
XAMPLE
ALU(config-pmap-P1-C1)# bandwidth 101
ALU(config-pmap-P1-C1)# no bandwidth
Command (in Class Mode) Description
set {ecn-ce|fr-becn|fr-de|fr-
fecn|ip-dscp {<0-63>|<dscp-
mnemonics>}|ip-precedence {<0-
7>|<precedence-mnemonics>}|tos
{<0-15>|<tos-mnemonics>}|vlan
1p}
This command can be used to set:
- IP Precedence/IP DSCP/ToS flags on
the matched packet
- FECN, BECN, DE bits marking on the
FR interface and
- 802.1p marking on the VLAN interface.
no set {ecn-ce|fr-becn|fr-
de|fr-fecn|ip-dscp|ip-
precedence|tos|vlan 1p}
This command removes the packet
marking configuration.
Command (in Class Mode) Description
bandwidth {<101-700000000>|
percent <1-100>}
This command is used to configure the
bandwidth for a traffic class.
101-700000000 - the absolute
bandwidth (bps) value.
1-100 - bandwidth in percentage.
no bandwidth This command removes the bandwidth
configuration.
