ARM Cortex-M3 User Manual

Nested Vectored Interrupt Controller
ARM DDI 0337G Copyright © 2005-2008 ARM Limited. All rights reserved. 8-9
Unrestricted Access Non-Confidential
Table 8-3 describes the bit assignments of the Auxiliary Control Register.
SysTick Control and Status Register
Use the SysTick Control and Status Register to enable the SysTick features.
The register address, access type, and Reset state are:
Address
0xE000E010
Access Read/write
Reset state
0x00000000
Figure 8-3 shows the bit assignments of the SysTick Control and Status Register.
Figure 8-3 SysTick Control and Status Register bit assignments
Table 8-3 Auxiliary Control Register bit assignments
Bits Field Function
[31:3] - Reserved
[2] DISFOLD Disables IT folding.
[1] DISDEFWBUF Disables write buffer use during default memory map accesses. This causes all bus faults to
be precise bus faults but decreases the performance of the processor because the stores to
memory have to complete before the next instruction can be executed.
[0] DISMCYCINT Disables interruption of multi-cycle instructions. This increases the interrupt latency of the
processor because LDM/STM completes before interrupt stacking occurs.
31
0
Reserved Reserved
16 1517
COUNTFLAG
12
CLKSOURCE
TICKINT
ENABLE

ARM Cortex-M3 Specifications

General

Architecture	ARMv7-M
Instruction Set	Thumb-2
Pipeline Stages	3-stage
Interrupts	Nested Vectored Interrupt Controller (NVIC)
Interrupt Controller	Nested Vectored Interrupt Controller (NVIC)
Memory Protection Unit	Optional
Power Consumption	Varies by implementation
Max Clock Speed	Up to 100 MHz
Debugging	JTAG and Serial Wire Debug (SWD)
Operating Voltage	1.8V to 3.6V
Manufacturing Process	Varies by implementation
Core Type	32-bit
