Exceptions
ARM DDI 0337G Copyright © 2005-2008 ARM Limited. All rights reserved. 5-21
Unrestricted Access Non-Confidential
0, // Populate if using MemManage (MPU)
0, // Populate if using Bus fault
0, // Populate if using Usage Fault
0, 0, 0, 0, // reserved slots
SVCallISR,
0, // Populate if using a debug monitor
0, // Reserved
0, // Populate if using pendable service request
0, // Populate if using SysTick
// external interrupts start here
Timer1ISR,
GpioInISR
GpioOutISR,
I2CIsr
};
Note
Vector table entries are ARM/Thumb interworking compatible. This causes bit [0] of
the vector value to load into the EPSR T-bit on exception entry. Creating a table entry
with bit [0] clear generates an INVSTATE fault on the first instruction of the handler
corresponding to this vector.
5.9.2 Intended boot-up sequence
A normal reset routine follows the steps shown in Table 5-8. A C/C++ runtime can
perform the first three steps and then call
main()
.
Table 5-8 Reset boot-up behavior
Action Description
Initialize variables Any global/static variables must be setup. This includes initializing the BSS variable to 0,
and copying initial values from ROM to RAM for non-constant variables.
[Setup stacks] If more than one stack is be used, the other banked SPs must be initialized. The current SP
can also be changed to Process from Main.
Initialize any runtime Optionally make calls to C/C++ runtime init code to enable use of heap, floating point, or
other features. This is normally done by
__main
from the C/C++ library.
[Initialize any peripherals] Setup peripherals before interrupts are enabled. This can call to setup each peripheral to be
used in the application.
[Switch ISR vector table] Optionally change vector table from Code area, @0, to a location in SRAM. This is only
done to optimize performance or enable dynamic changes.
[Setup Configurable Faults] Enable Configurable faults and set their priorities.
