6.2 Resets

The processor has three reset inputs. Table 6-3 describes the reset inputs.

Note

nTRST resets SWJ-DP. If your implementation does not contain SWJ-DP, this reset

must be tied off.

Table 6-3 Reset inputs

Reset input Description

PORESETn Resets the entire processor system with the exception of SWJ-DP

SYSRESETn Resets the entire processor system with the exception of debug logic in the:

• Nested Vectored Interrupt Controller (NVIC)

• Flash Patch and Breakpoint (FPB)

• Data Watchpoint and Trace (DWT)

• Instrumentation Trace Macrocell (ITM)

• AHB-AP.

nTRST SWJ-DP reset
