Memory Protection Unit

Unrestricted Access Non-Confidential

Unless HFNMIENA is set, the MPU is not enabled when the exception priority is –1 or

–2. These priorities are only possible when in Hard fault, NMI, or when FAULTMASK

is enabled. The HFNMIENA bit enables the MPU when operating with these two

priorities.

The register address, access type, and Reset state are:

Address

0xE000ED94

Access Read/write

Reset state

0x00000000

Figure 9-2 shows the bit assignments of the MPU Control Register.

Figure 9-2 MPU Control Register bit assignments

31 10

Reserved

HFNMIENA

ENABLE

PRIVDEFENA
