ARM Cortex-M3 User Manual

Nested Vectored Interrupt Controller
8-14 Copyright © 2005-2008 ARM Limited. All rights reserved. ARM DDI 0337G
Non-Confidential
Unrestricted Access
Table 8-8 describes the field of the Interrupt Set-Enable Register.
Interrupt Clear-Enable Registers
Use the Interrupt Clear-Enable Registers to:
• disable interrupts
• determine which interrupts are currently disabled.
Each bit in the register corresponds to one of the 32 interrupts. Setting an Interrupt
Clear-Enable Register bit disables the corresponding interrupt.
The register address, access type, and Reset state are:
Address
0xE000E180-0xE000E19C
Access Read/write
Reset state
0x00000000
Table 8-9 describes the field of the Interrupt Clear-Enable Register.
Table 8-8 Interrupt Set-Enable Register bit assignments
Bits Field Function
[31:0] SETENA Interrupt set enable bits. For write operation:
1 = enable interrupt
0 = no effect.
For read operation:
1 = enable interrupt
0 = disable interrupt
Writing 0 to a SETENA bit has no effect. Reading the bit returns its current enable state. Reset clears
the SETENA fields.
Table 8-9 Interrupt Clear-Enable Register bit assignments
Bits Field Function
[31:0] CLRENA Interrupt clear-enable bits. For write operation:
1 = disable interrupt
0 = no effect.
For read operation:
1 = enable interrupt
0 = disable interrupt.
Writing 0 to a CLRENA bit has no effect. Reading the bit returns its current enable state.

ARM Cortex-M3 Specifications

General

Architecture	ARMv7-M
Instruction Set	Thumb-2
Pipeline Stages	3-stage
Interrupts	Nested Vectored Interrupt Controller (NVIC)
Interrupt Controller	Nested Vectored Interrupt Controller (NVIC)
Memory Protection Unit	Optional
Power Consumption	Varies by implementation
Max Clock Speed	Up to 100 MHz
Debugging	JTAG and Serial Wire Debug (SWD)
Operating Voltage	1.8V to 3.6V
Manufacturing Process	Varies by implementation
Core Type	32-bit
