A.14 Test interface

Table A-14 lists the signals of the test interface.

Table A-14 Test interface

Name Direction Description

SE Input Scan enable.

RSTBYPASS Input Reset bypass for scan testing. PORESETn is the only reset used during scan testing.

CGBYPASS Input Architectural clock gate bypass for scan testing.
