Trace Port Interface Unit

APB interface

Table 17-4 describes the APB interface inputs.

SWOACTIVE Output SWO mode selected. Use for pin multiplexing.

TPIUACTIV Output Indicates that the TPIU has data that is in the process of being output.

TPIUBAUD Output Toggles at baud frequency (in TRACECLKIN domain).

Table 17-3 Miscellaneous configuration inputs (continued)

Name Type Description

Table 17-4 APB interface

Name Type Description

PSEL Input Peripheral select

PWRITE Input Peripheral write control

PENABLE Input Peripheral transfer enable

PADDR[11:2] Input Peripheral address

PWDATA[31:0] - Write data

PRDATA[31:0] - Read data
