System Debug

Non-Confidential

Unrestricted Access

11.4 FPB

The FPB:

• implements hardware breakpoints

• patches code and data from code space to system space.

A full FPB unit contains:

• Two literal comparators for matching against literal loads from Code space, and

remapping to a corresponding area in System space.

• Six instruction comparators for matching against instruction fetches from Code

space, and remapping to a corresponding area in System space. Alternatively, you

can individually configure the comparators to return a Breakpoint Instruction

(BKPT) to the processor core on a match, so providing hardware breakpoint

capability.

The FPB contains a global enable, but also individual enables for the eight comparators.

If the comparison for an entry matches, the address is remapped to the address set in the

remap register plus an offset corresponding to the comparator that matched, or is

remapped to a BKPT instruction if that feature is enabled. The comparison happens

dynamically, but the result of the comparison occurs too late to stop the original

instruction fetch or literal load taking place from the Code space. The processor ignores

this transaction however, and only the remapped transaction is used.

If an MPU is present, the MPU lookups are performed for the original address, not the

remapped address.

You can remove the FPB if no debug is required or alternatively the number of

breakpoints it supports can be reduced to two. If the FPB supports only two breakpoints

then only comparators 0 and 1 are used, and flash patching is not supported.

Note

• Unaligned literal accesses are not remapped. The original access to the DCode

bus takes place in this case.

• Load exclusives are Unpredictable to the FPB. The address is remapped but the

access does not take place as an exclusive load.

• Remapping to the bit-band alias directly accesses the alias address, and does not

remap to the bit-band region.

11.4.1 FPB programmer’s model

Table 11-1 on page 11-7 lists the flash patch registers.
