ARM Cortex-M3 User Manual

AC Characteristics
ARM DDI 0337G Copyright © 2005-2008 ARM Limited. All rights reserved. 19-5
Unrestricted Access Non-Confidential
Table 19-7 shows the timing parameters for the test input ports.
Table 19-8 shows the timing parameters for the Embedded Trace Macrocell (ETM).
Table 19-9 shows the timing parameters for the miscellaneous output ports.
Table 19-7 Test input ports timing parameters
Input delay Min. Input delay Max. Signal name
Clock uncertainty 10% SE
Clock uncertainty 10% SI
Clock uncertainty 10% RSTBYPASS
Clock uncertainty 10% CGBYPASS
Clock uncertainty 10% WSII
Clock uncertainty 10% WSOI
Table 19-8 ETM input port timing parameters
Input delay Min. Input delay Max. Signal name
Clock uncertainty 30% ETMPWRUP
Clock uncertainty 50% ETMFIFOFILL
Table 19-9 Miscellaneous output ports timing parameters
Output delay Min. Output delay Max. Signal name
Clock uncertainty 50% LOCKUP
Clock uncertainty 50% SYSRESETREQ
Clock uncertainty 50% BRCHSTAT[3:0]
Clock uncertainty 50% HALTED
Clock uncertainty 50% TXEV
Clock uncertainty 50% ATIDITM[6:0]

ARM Cortex-M3 Specifications

General

Architecture	ARMv7-M
Instruction Set	Thumb-2
Pipeline Stages	3-stage
Interrupts	Nested Vectored Interrupt Controller (NVIC)
Interrupt Controller	Nested Vectored Interrupt Controller (NVIC)
Memory Protection Unit	Optional
Power Consumption	Varies by implementation
Max Clock Speed	Up to 100 MHz
Debugging	JTAG and Serial Wire Debug (SWD)
Operating Voltage	1.8V to 3.6V
Manufacturing Process	Varies by implementation
Core Type	32-bit
