When used in this way, the value written to the PC is intercepted and is referred to as
the EXC_RETURN value.
EXC_RETURN[3:0] provides return information as defined in
Table 5-6.
Reserved entries in this table result in a chained exception to a Usage Fault.
If an EXC_RETURN value is loaded into the PC when in Thread mode, or from the
vector table, or by any other instruction, the value is treated as an address, not as a
special value. This address range is defined to have Execute Never (XN) permissions,
and results in a MemManage fault.
Table 5-6 Exception return behavior
EXC_RETURN[3:0] Description
0bXXX0 Reserved.
0b0001 Return to Handler mode.
Exception return gets state from the main stack.
On return execution uses the main stack.
0b0011 Reserved.
0b01X1 Reserved.
0b1001 Return to Thread mode.
Exception return gets state from the main stack.
On return execution uses the main stack.
0b1101 Return to Thread mode.
Exception return gets state from the process stack.
On return execution uses the process stack.
0b1X11 Reserved.

ARM Cortex-M3 Specifications

General

Architecture	ARMv7-M
Instruction Set	Thumb-2
Pipeline Stages	3-stage
Interrupts	Nested Vectored Interrupt Controller (NVIC)
Interrupt Controller	Nested Vectored Interrupt Controller (NVIC)
Memory Protection Unit	Optional
Power Consumption	Varies by implementation
Max Clock Speed	Up to 100 MHz
Debugging	JTAG and Serial Wire Debug (SWD)
Operating Voltage	1.8V to 3.6V
Manufacturing Process	Varies by implementation
Core Type	32-bit
