Exceptions
5-8 Copyright © 2005-2008 ARM Limited. All rights reserved. ARM DDI 0337G
Non-Confidential
Unrestricted Access
Table 5-3 shows how writing to PRIGROUP splits an eight bit PRI_N field into a
pre-emption priority field (x) and a subpriority field (y).
Note
Table 5-3 shows the priorities for the processor configured with eight bits of
priority.
For a processor configured with less than eight bits of priority, the lower bits of
the register are always 0. For example, if four bits of priority are implemented,
PRI_N[7:4] sets the priority, and PRI_N[3:0] is 4'b0000.
An interrupt can pre-empt another interrupt in progress only if its pre-emption priority
is higher than that of the interrupt in progress.
For more information on priority optimizations, priority level grouping, and priority
masking, see the ARMv7-M Architecture Reference Manual.
Table 5-3 Priority grouping
Interrupt priority level field, PRI_N[7:0]
PRIGROUP[2:0]
Binary point
position Pre-emption field Subpriority field
Number of
pre-emption
priorities
Number of
subpriorities
b000 bxxxxxxx.y [7:1] [0] 128 2
b001 bxxxxxx.yy [7:2] [1:0] 64 4
b010 bxxxxx.yyy [7:3] [2:0] 32 8
b011 bxxxx.yyyy [7:4] [3:0] 16 16
b100 bxxx.yyyyy [7:5] [4:0] 8 32
b101 bxx.yyyyyy [7:6] [5:0] 4 64
b110 bx.yyyyyyy [7] [6:0] 2 128
b111 b.yyyyyyyy None [7:0] 0 256
