Signal Descriptions

Non-Confidential

Unrestricted Access

A.10 ITM interface

Table A-10 lists the signals of the ITM interface.

Table A-10 ITM interface

Name Direction Description

ATVAL ID Output ATB valid.

AFREADY Output ATB flush.

ATDATA[7:0] Output ATB data.

ATIDITM[6:0] Output ITM ID for TPIU.

ATREADY Input ATB ready.

TPIUACTV Input TPIU active indication signal.

TPIUBAUD Input Reference for the timestamp counter, so that timestamps are at the observable baud rate

of the external protocol.
