Nested Vectored Interrupt Controller
8-32 Copyright © 2005-2008 ARM Limited. All rights reserved. ARM DDI 0337G
Non-Confidential
Unrestricted Access
Configurable Fault Status Registers
Use the three Configurable Fault Status Registers to obtain information about local
faults. These registers include:
Memory Manage Fault Status Register
Bus Fault Status Register on page 8-34
Usage Fault Status Register on page 8-35.
The flags in these registers indicate the causes of local faults. Multiple flags can be set
if more than one fault occurs. These register are read/write-clear. This means that they
can be read normally, but writing a 1 to any bit clears that bit.
The register addresses, access types, and Reset states are:
Address
0xE000ED28
Memory Manage Fault Status Register
0xE000ED29
Bus Fault Status Register
0xE000ED2A
Usage Fault Status Register
Access Read/write-one-to-clear
Reset state
0x00000000
Figure 8-16 shows the bit assignments of the Configurable Fault Status Registers.
Figure 8-16 Configurable Fault Status Registers bit assignments
Note
Accesses to each individual status register must be aligned to the appropriate address
and size. Either the whole 32-bit word is accessed using address
0xE000ED28
or the BFSR
and MFSR are accessed as a byte size each correctly aligned or the UFSR is accessed
as a half-word correctly aligned to address
0xE000ED2A
.
Memory Manage Fault Status Register
The flags in the Memory Manage Fault Status Register indicate the cause of memory
access faults.
The register address, access type, and Reset state are:
Address
0xE000ED28
Access Read/write-one-to-clear
Reset state
0x00000000
31 16 15 8 7 0
Bus Fault Status
Register
Usage Fault Status
Register
Memory Manage
Fault Status Register
