ARM Cortex-M3 User Manual

Core Debug
ARM DDI 0337G Copyright © 2005-2008 ARM Limited. All rights reserved. 10-7
Unrestricted Access Non-Confidential
Table 10-3 shows the bit functions of the Debug Core Selector Register.
This write-only register generates a handshake to the core to transfer data to or from
Debug Core Register Data Register and the selected register. Until this core transaction
is complete, bit [16], S_REGRDY, of the DHCSR is 0.
Note
• Writes to this register in any size but word are Unpredictable.
• PSR registers are fully accessible this way, whereas some read as 0 when using
MRS instructions.
• All bits can be written, but some combinations cause a fault when execution is
resumed.
• IT might be written and behaves as though in an IT block.
Table 10-3 Debug Core Register Selector Register
Bits Type Field Function
[31:17] - - Reserved
[16] Write REGWnR Write = 1
Read = 0
[15:5] - - Reserved.
[4:0] Write REGSEL 5b00000 = R0
5b00001 = R1
…
5b01111 = DebugReturnAddress()
5b10000 = xPSR/Flags, execution state information, and exception
number
5b10001 = MSP (Main SP)
5b10010 = PSP (Process SP)
5b10100:
• CONTROL bits [31:24]
• FAULTMASK bits [23:16]
• BASEPRI bits [15:8]
• PRIMASK bits [7:0]
All unused values reserved

ARM Cortex-M3 Specifications

General

Architecture	ARMv7-M
Instruction Set	Thumb-2
Pipeline Stages	3-stage
Interrupts	Nested Vectored Interrupt Controller (NVIC)
Interrupt Controller	Nested Vectored Interrupt Controller (NVIC)
Memory Protection Unit	Optional
Power Consumption	Varies by implementation
Max Clock Speed	Up to 100 MHz
Debugging	JTAG and Serial Wire Debug (SWD)
Operating Voltage	1.8V to 3.6V
Manufacturing Process	Varies by implementation
Core Type	32-bit
