ARM Cortex-M3 User Manual

Core Debug
10-6 Copyright © 2005-2008 ARM Limited. All rights reserved. ARM DDI 0337G
Non-Confidential
Unrestricted Access
If not enabled for Halting mode, C_DEBUGEN = 1, all other fields are disabled.
This register is not reset on a system reset. It is reset by a power-on reset. However, the
C_HALT bit always clears on a system reset.
To halt on a reset, the following bits must be enabled:
•bit [0], VC_CORERESET, of the Debug Exception and Monitor Control
Register
•bit [0],C_DEBUGEN, of the Debug Halting Control and Status Register.
Note
Writes to this register in any size other than word are Unpredictable. It is acceptable to
read in any size, and you can use it to avoid or intentionally change a sticky bit.
10.2.2 Debug Core Register Selector Register
The purpose of the Debug Core Register Selector Register (DCRSR) is to select the
processor register to transfer data to or from.
The DCRSR:
• is a 17-bit write-only register
• address is
0xE000EDF4 .
Figure 10-2 shows the bit assignments in the register.
Figure 10-2 Debug Core Register Selector Register bit assignments
REGSELReserved
REGWnR
31 0151617
Reserved
45

ARM Cortex-M3 Specifications

General

Architecture	ARMv7-M
Instruction Set	Thumb-2
Pipeline Stages	3-stage
Interrupts	Nested Vectored Interrupt Controller (NVIC)
Interrupt Controller	Nested Vectored Interrupt Controller (NVIC)
Memory Protection Unit	Optional
Power Consumption	Varies by implementation
Max Clock Speed	Up to 100 MHz
Debugging	JTAG and Serial Wire Debug (SWD)
Operating Voltage	1.8V to 3.6V
Manufacturing Process	Varies by implementation
Core Type	32-bit
