Nested Vectored Interrupt Controller

Unrestricted Access Non-Confidential

8.2.2 NVIC register descriptions

The sections that follow describe how to use the NVIC registers.

Note

The Memory Protection Unit (MPU) registers, and the debug registers are described in

Chapter 9 Memory Protection Unit and Chapter 10 Core Debug respectively.

Interrupt Controller Type Register

Read the Interrupt Controller Type Register to see the number of interrupt lines that the

NVIC supports.

The register address, access type, and Reset state are:

Address

0xE000E004

Access Read-only

Reset state Depends on the number of interrupts defined in this processor

implementation.

Figure 8-1 shows the bit assignments of the Interrupt Controller Type Register.

Figure 8-1 Interrupt Controller Type Register bit assignments

31 54 0

INTLINESNUM

Reserved
