ARM Cortex-M3 User Manual

System Debug
ARM DDI 0337G Copyright © 2005-2008 ARM Limited. All rights reserved. 11-41
Unrestricted Access Non-Confidential
Figure 11-19 AHB-AP Control and Status Word Register
Table 11-29 describes the bit assignments of the AHB-AP Control and Status Word
Register.
11 831 29 28 2630 12 7 6 5 4 3 2 0
MODEReserved SIZE
25 24
TransInProg
DbgStatus
AddrInc
Hprot1
MasterType
Reserved
Reserved Reserved
Table 11-29 AHB-AP Control and Status Word Register bit assignments
Bits Field Function
[31:30] - Reserved. Read as 0b00.
[29]
MasterType
a
0 = core.
1 = debug.
It cannot be changed if transaction is outstanding. Debugger must first check TransinProg.
Reset value = 0b1.
If the FIXHMASTERTYPE input signal is set to 1 then this register has no affect on the
master value indicated by the transaction. It is always marked as the debugger.
[28:26] - Reserved, 0b000.
[25] Hprot1 User/Privilege control - HPROT[1].
Reset value = 0b1.
[24] - Reserved, 0b1.
[23:12] - Reserved,
0x000 .
[11:8] Mode Mode of operation bits:
b0000 = normal download/upload mode
b0001-b1111 are reserved.
Reset value = 0b0000.
[7] TransINProg Transfer in progress. This field indicates if a transfer is in progress on the APB master port.
[6] DbgStatus Indicates the status of the DAPEN port. If DbgStatus is LOW, no AHB transfers carried out.
1 = AHB transfers permitted.
0 = AHB transfers not permitted.
