ARM Cortex-M3 User Manual

Nested Vectored Interrupt Controller
ARM DDI 0337G Copyright © 2005-2008 ARM Limited. All rights reserved. 8-37
Unrestricted Access Non-Confidential
Note
The fault bits are additive if more than one fault occurs before this register is cleared.
Hard Fault Status Register
Use the Hard Fault Status Register (HFSR) to obtain information about events that
activate the Hard Fault handler.
The register address, access type, and Reset state are:
Address
0xE000ED2C
Access Read/write-one-to-clear
Reset state
0x00000000
The HFSR is a write-clear register. This means that writing a 1 to a bit clears that bit.
Figure 8-20 shows the bit assignments of the Hard Fault Status Register.
Figure 8-20 Hard Fault Status Register bit assignments
[2] INVPC Attempt to load EXC_RETURN into PC illegally. Invalid instruction, invalid context, invalid
value. The return PC points to the instruction that tried to set the PC.
[1] INVSTATE Invalid combination of EPSR and instruction, for reasons other than UNDEFINED
instruction. Return PC points to faulting instruction, with the invalid state.
[0] UNDEFINSTR The UNDEFINSTR flag is set when the processor attempts to execute an undefined
instruction. This is an instruction that the processor cannot decode. The return PC points to
the undefined instruction.
Table 8-24 Usage Fault Status Register bit assignments (continued)
Bits Field Function
31 30 210
Reserved
29
DEBUGEVT
FORCED VECTTBL
Reserved

ARM Cortex-M3 Specifications

General

Architecture	ARMv7-M
Instruction Set	Thumb-2
Pipeline Stages	3-stage
Interrupts	Nested Vectored Interrupt Controller (NVIC)
Interrupt Controller	Nested Vectored Interrupt Controller (NVIC)
Memory Protection Unit	Optional
Power Consumption	Varies by implementation
Max Clock Speed	Up to 100 MHz
Debugging	JTAG and Serial Wire Debug (SWD)
Operating Voltage	1.8V to 3.6V
Manufacturing Process	Varies by implementation
Core Type	32-bit
