Page #366 background image
AC Characteristics
19-4 Copyright © 2005-2008 ARM Limited. All rights reserved. ARM DDI 0337G
Non-Confidential
Unrestricted Access
Table 19-5 shows the timing parameter for the Private Peripheral Bus (PPB) port.
Table 19-6 shows the timing parameters for the debug input ports.
Table 19-5 PPB input port timing parameters
Input delay Min. Input delay Max. Signal name
Clock uncertainty 50% PRDATA[31:0]
Clock uncertainty 50% PREADY
Clock uncertainty 50% PSLVERR
Table 19-6 Debug input ports timing parameters
Input delay Min. Input delay Max. Signal name
Clock uncertainty 10% nTRST
Clock uncertainty 50% SWDITMS
Clock uncertainty 50% TDI
Clock uncertainty 50% DAPRESETn
Clock uncertainty 50% DAPSEL
Clock uncertainty 50% DAPEN
Clock uncertainty 50% DAPENABLE
Clock uncertainty 50% DAPCLKEN
Clock uncertainty 50% DAPWRITE
Clock uncertainty 50% DAPABORT
Clock uncertainty 50% DAPADDR[31:0]
Clock uncertainty 50% DAPWDATA[31:0]
Clock uncertainty 50% ATREADY
Clock uncertainty 50% DBGRESTART
Clock uncertainty 50% FIXHMASTERTYPE
