ARM Cortex-M3

To Next Page

To Previous Page

Embedded Trace Macrocell

Non-Confidential

Unrestricted Access

14.3 ETM resources

Because the ETM does not generate data trace information, the lower bandwidth

reduces the requirement for complex triggering capabilities. This means that the ETM

does not include the following:

• internal comparators

• counters

• sequencers.

Table 14-7 lists the Cortex-M3 resources.

Table 14-7 Cortex-M3 resources

Feature Present on Cortex-M3 ETM

Architecture version ETMv3.4

Address comparator pairs 0

Data comparators 0

Context ID comparators 0

MMDs 0

Counters 0

Sequencer No

Start/stop block Yes

Embedded ICE comparators 4

External inputs 2

External outputs 0

Extended external inputs 0

Extended external input selectors 0

FIFOFULL Yes

FIFOFULL level setting Yes

Branch broadcasting Yes

ASIC Control Register No

Data suppression No
