ARM Cortex-M3 User Manual

Nested Vectored Interrupt Controller
8-18 Copyright © 2005-2008 ARM Limited. All rights reserved. ARM DDI 0337G
Non-Confidential
Unrestricted Access
Table 8-13 describes the bit assignments of the Interrupt Priority Registers, where n
specifies the number of interrupts and is greater than 0 and less than or equal to 240.
CPU ID Base Register
Read the CPU ID Base Register to determine:
• the ID number of the processor core
• the version number of the processor core
• the implementation details of the processor core.
The register address, access type, and Reset state are:
Address
0xE000ED00
Access Read-only
Reset state
0x412FC230
Figure 8-8 shows the bit assignments of the CPUID Base Register.
Figure 8-8 CPUID Base Register bit assignments
Table 8-14 describes the bit assignments of the CPUID Base Register.
Table 8-13 Interrupt Priority Registers 0-31 bit assignments
Bits Field Function
[7:0] PRI_n Priority of interrupt n
31 16 15 4 3 0
IMPLEMENTER
REVISIONPARTNO
24 23 20 19
VARIANT Constant
Table 8-14 CPUID Base Register bit assignments
Bits Field Function
[31:24] IMPLEMENTER Implementer code. ARM is
0x41
[23:20] VARIANT Implementation defined variant number.

ARM Cortex-M3 Specifications

General

Architecture	ARMv7-M
Instruction Set	Thumb-2
Pipeline Stages	3-stage
Interrupts	Nested Vectored Interrupt Controller (NVIC)
Interrupt Controller	Nested Vectored Interrupt Controller (NVIC)
Memory Protection Unit	Optional
Power Consumption	Varies by implementation
Max Clock Speed	Up to 100 MHz
Debugging	JTAG and Serial Wire Debug (SWD)
Operating Voltage	1.8V to 3.6V
Manufacturing Process	Varies by implementation
Core Type	32-bit
