System Debug
ARM DDI 0337G Copyright © 2005-2008 ARM Limited. All rights reserved. 11-25
Unrestricted Access Non-Confidential
DWT Mask Registers 0-3
Use the DWT Mask Registers 0-3 to apply a mask to data addresses when matching
against COMP.
The register address, access type, and Reset state are:
Address
0xE0001024
,
0xE0001034
,
0xE0001044
,
0xE0001054
Access Read/write
Reset state -
Figure 11-11 shows the bit assignments of DWT Mask Registers 0-3.
Figure 11-11 DWT Mask Registers 0-3 bit assignments
Table 11-16 describes the bit assignments of DWT Mask Registers 0-3.
DWT Function Registers 0-3
Use the DWT Function Registers 0-3 to control the operation of the comparator. Each
comparator can:
Match against either the PC or the data address. This is controlled by
CYCMATCH. This function is only available for comparator 0 (DWT_COMP0).
Perform data value comparisons if associated address comparators have
performed an address match. This function is only available for comparator 1
(DWT_COMP1).
31 0
Reserved
4
MASK
3
Table 11-16 DWT Mask Registers 0-3 bit assignments
Bits Field Function
[31:4] - Reserved.
[3:0] MASK Mask on data address when matching against COMP. This is the size of the ignore mask.
So, ~0<<MASK forms the mask against the address to use. That is, DWT matching is performed
as:
(ADDR & (~0 << MASK)) == COMP
However, the actual comparison is slightly more complex to enable matching an address wherever it
appears on a bus. So, if COMP is 3, this matches a word access of 0, because 3 would be within the
word.
